PAUT A10 Series Flat Wedges for A10 Probe Series

PAUT A10 Series Flat Wedges for A10 Probe Series

Brand: TheSonic India
Product Name: PAUT A10 Series Flat Wedges
Probe Series Compatibility: A10 Probe Series
Product Type: Flat PAUT Wedge
Inspection Method: PAUT / Phased Array Ultrasonic Testing
Material: Rexolite
Application: Flat surface weld inspection and general phased array weld scanning
Email: i@thesonic.com

Product Overview

TheSonic India PAUT A10 Series Flat Wedges are designed for phased array ultrasonic testing applications where a flat contact surface is required for weld inspection. The wedge acts as the acoustic interface between the A10 Probe Series PAUT probe and the test component, helping transfer ultrasonic sound into the material with controlled beam direction and consistent surface contact.

The flat wedge configuration is suitable for applications where the inspection surface does not require outside-diameter or inside-diameter curvature matching. It is commonly used for plate welds, flat fabrication joints, structural welds, flat shell areas, pad welds, and general industrial weld examination.

Manufactured from high-quality Rexolite material, the A10 Series Flat Wedge supports efficient ultrasonic sound transmission, dimensional stability, and reliable acoustic performance. The wedge is supported with high-quality, high-standard damping material designed with a zero-tolerance approach toward unwanted ultrasonic sound acceptance. This damping support helps absorb, control, and divert unwanted ultrasonic energy, reducing unnecessary internal reflections, wedge noise, and signal disturbance during inspection.

Key Features

·       Designed for A10 Probe Series PAUT weld inspection applications

·       Flat contact design for flat and near-flat inspection surfaces

·       Manufactured from high-quality Rexolite material

·       Suitable for phased array ultrasonic weld inspection

·       Supports stable ultrasonic coupling and smooth scanning movement

·       Helps maintain accurate beam positioning and consistent sound entry

·       Suitable for plate welds, structural welds, fabrication welds, and flat inspection zones

·       High-quality damping material to absorb, control, and divert unwanted ultrasonic energy

·       Helps reduce unwanted wedge reflections, internal noise, and signal disturbance

·       Suitable for manual PAUT scanning and scanner-assisted inspection where applicable

·       Can be supplied for different OEM and international PAUT probe models, subject to dimensional confirmation

·       Suitable for industrial NDT, fabrication, maintenance, shutdown, and quality control applications

Detailed Product Description

The PAUT A10 Series Flat Wedge from TheSonic India is developed for reliable phased array ultrasonic weld inspection on flat and near-flat surfaces. In PAUT inspection, wedge design is important because it influences sound transmission, probe stability, beam angle control, and inspection repeatability.

This flat wedge version is selected when the inspection surface allows direct flat contact. The flat bottom profile helps the wedge remain steady on plates, flat weld zones, structural members, and fabricated components. This helps reduce unwanted rocking movement, supports consistent couplant behavior, and improves scan repeatability during phased array inspection.

The Rexolite wedge body supports dependable ultrasonic energy transfer from the probe into the inspected component. The high-standard damping support is designed to manage unwanted sound paths inside the wedge and divert unnecessary ultrasonic energy. This helps improve signal clarity and supports cleaner PAUT data acquisition.

Flat Wedge Application

The Flat Wedge configuration is recommended for flat surface weld inspection where OD or ID curvature matching is not required. It is suitable for direct scanning on flat plates, fabricated weld joints, structural members, and flat inspection areas.

Unlike AOD, COD, AID, and CID wedge types, the flat wedge is not designed for curved-surface matching. It is selected when the test surface provides stable contact for a flat wedge base.

Typical Applications

·       PAUT weld inspection on flat surfaces

·       Plate-to-plate weld inspection

·       Structural fabrication weld inspection

·       Flat shell and pad weld inspection

·       General fabrication weld quality control

·       Heavy engineering component inspection

·       Flat pressure component weld inspection

·       Manual phased array ultrasonic testing

·       Scanner-assisted PAUT weld scanning where applicable

·       Workshop, site, maintenance, and shutdown inspection applications

Suitable Inspection Areas

The PAUT A10 Series Flat Wedge is suitable for flat plates, flat weld joints, structural welds, fabricated components, pad welds, blocks, and near-flat inspection surfaces.

For pipe, vessel, nozzle, tube, or cylindrical component inspection, AOD, COD, AID, or CID wedge configurations may be selected based on surface curvature and scanning direction.

Technical Information

Universal Probe Compatibility

TheSonic India PAUT A10 Series Flat Wedges are designed for A10 Probe Series applications and can also be supplied to suit different phased array probe models from reputed worldwide OEM brands. Compatibility can be confirmed based on probe dimensions, probe housing design, mounting arrangement, cable exit direction, active aperture, element configuration, and inspection requirement.

Details Required for Compatibility Confirmation

·       Probe brand and model number

·       Probe series and probe drawing

·       Number of elements

·       Element pitch

·       Active aperture size

·       Probe housing dimensions

·       Mounting hole position

·       Cable exit direction

·       Required refracted angle

·       Inspection material

·       Required wedge type: Flat

·       Manual or scanner-based inspection requirement

Customization Options

·       Probe fitting arrangement

·       Wedge angle selection

·       Wedge footprint and height

·       Mounting hole arrangement

·       Scanner interface requirement

·       Irrigation or couplant feed option

·       Wear-resistant contact surface option

·       Engraved part number or identification marking

·       Application-specific wedge design

·       OEM probe compatibility modification

Recommended Industries

·       Oil & Gas

·       Petrochemical Plants

·       Refineries

·       Power Plants

·       Boiler and Pressure Vessel Fabrication

·       Pipeline and Process Piping Fabrication

·       Structural Fabrication

·       Heavy Engineering

·       Shipbuilding and Marine Fabrication

·       Plant Maintenance and Shutdown Inspection

·       NDT Service Companies

·       Inspection and Quality Control Laboratories

Why Choose TheSonic India PAUT A10 Series Flat Wedges?

TheSonic India PAUT A10 Series Flat Wedges are designed for dependable phased array ultrasonic weld inspection using A10 Probe Series applications. The product combines Rexolite wedge material, stable flat surface contact, controlled ultrasonic beam positioning, and high-standard damping support to deliver reliable inspection performance.

These wedges are suitable for customers looking for accurate, durable, and application-ready PAUT weld inspection accessories with A10 Probe Series compatibility, OEM probe adaptability, and customization support.

Contact note

For technical details, probe compatibility confirmation, product customization, commercial quotation, or bulk supply requirements, please contact TheSonic India.

Email: i@thesonic.com
Brand: TheSonic India
