PAUT A12 Series COD Wedges for A12 Probe Series

PAUT A12 Series COD Wedges for A12 Probe Series

Brand: TheSonic India
Product Name: PAUT A12 Series COD Wedges
Probe Series Compatibility: A12 Probe Series
Product Type: COD PAUT Wedge
COD Meaning: Circumferential Outer Diameter Wedge
Inspection Method: PAUT / Phased Array Ultrasonic Testing
Material: Rexolite
Application: Circumferential weld inspection on outer-diameter curved surfaces
Email: i@thesonic.com

Product Overview

TheSonic India PAUT A12 Series COD Wedges are developed for phased array ultrasonic testing applications where the wedge must contact the outside diameter of a curved component and support circumferential inspection orientation. This configuration is suitable for pipe welds, pressure vessel welds, cylindrical shell welds, nozzle welds, headers, and other round components requiring OD curved surface inspection.

The COD wedge is selected when the inspection arrangement requires the wedge to follow the circumferential profile of the component. Its OD curved contact surface helps improve seating, coupling stability, and probe control during PAUT weld inspection. Stable wedge contact is important for maintaining consistent ultrasonic transmission and reliable inspection data quality.

Manufactured from high-quality Rexolite material, the A12 Series COD Wedge supports efficient ultrasonic sound transmission, dimensional stability, and dependable acoustic performance. The wedge is supported with high-quality, high-standard damping material designed with a zero-tolerance approach toward unwanted ultrasonic sound acceptance. This damping support helps absorb, control, and divert unwanted ultrasonic energy, reducing unwanted wedge reflections, internal noise, and signal disturbance.

Key Features

·       Designed for A12 Probe Series PAUT weld inspection applications

·       COD configuration for circumferential OD curved surface inspection

·       Manufactured from high-quality Rexolite material

·       Suitable for pipes, vessels, shells, nozzles, headers, and cylindrical components

·       OD curved contact profile supports stable seating on outside-diameter surfaces

·       Helps maintain consistent probe orientation during circumferential weld inspection

·       Supports controlled beam entry and reliable ultrasonic transmission

·       High-quality damping material to absorb, control, and divert unwanted ultrasonic energy

·       Helps reduce unwanted internal reflections, wedge noise, and signal disturbance

·       Suitable for manual PAUT scanning and scanner-assisted inspection

·       Can be supplied for different OEM and international PAUT probe models, subject to dimensional confirmation

·       Suitable for fabrication, in-service inspection, maintenance, and shutdown applications

Detailed Product Description

The PAUT A12 Series COD Wedge from TheSonic India is designed for circumferential outer-diameter weld inspection using A12 Probe Series phased array probes. This wedge is selected when the probe and wedge arrangement must follow the outside curved profile of a pipe, vessel, shell, nozzle, or cylindrical component.

The COD wedge differs from the AOD wedge because COD supports circumferential OD inspection, while AOD supports axial OD inspection. Selecting the correct wedge orientation is important for curved component inspection because the contact profile must match the surface geometry and scanning requirement. The COD profile helps maintain stable seating around the outer curved surface, supporting improved coupling and steady probe orientation.

The Rexolite wedge body supports effective ultrasonic energy transfer into the test component. The high-standard damping support helps control unwanted ultrasonic sound paths inside the wedge and supports cleaner, more reliable PAUT inspection data.

COD Wedge Application

The COD Wedge configuration is recommended for outer-diameter curved surfaces where the inspection requirement is circumferential. It is commonly used when the wedge must sit on the outside surface of a cylindrical component and support inspection orientation around the circumference.

COD is different from AOD because COD supports circumferential OD inspection, while AOD supports axial OD inspection.

Typical Applications

·       PAUT weld inspection on circumferential OD curved surfaces

·       Pipe and vessel circumferential weld inspection

·       Cylindrical shell weld inspection

·       Pipeline and pressure component inspection

·       Nozzle and pipe connection weld inspection

·       Boiler header and curved component inspection

·       Refinery and petrochemical plant weld inspection

·       Power plant and process piping inspection

·       Manual phased array ultrasonic testing

·       Scanner-assisted PAUT inspection where applicable

·       Fabrication, maintenance, shutdown, and in-service inspection

Suitable Inspection Areas

The PAUT A12 Series COD Wedge is suitable for OD curved surfaces where circumferential curvature matching is required. It is commonly used for pipes, vessels, shells, nozzles, headers, and cylindrical components.

For flat surfaces, Flat Wedge is recommended. For axial OD inspection, AOD Wedge may be selected. For internal curved surface inspection, AID or CID configurations may be required.

Technical Information

Universal Probe Compatibility

TheSonic India PAUT A12 Series COD Wedges are designed for A12 Probe Series applications and can also be supplied to suit different phased array probe models from reputed worldwide OEM brands. Final compatibility can be confirmed based on probe dimensions, mounting arrangement, cable exit direction, active aperture, element configuration, OD curvature requirement, and inspection application.

Details Required for Compatibility Confirmation

·       Probe brand and model number

·       Probe series and probe drawing

·       Number of elements

·       Element pitch

·       Active aperture size

·       Probe housing dimensions

·       Mounting hole position

·       Cable exit direction

·       Required refracted angle

·       Inspection material

·       Component outside diameter

·       Required curvature type: COD

·       Manual or scanner-based inspection requirement

Customization Options

·       Circumferential OD curvature matching

·       Probe fitting arrangement

·       Wedge angle selection

·       Wedge footprint and height

·       Mounting hole arrangement

·       Scanner interface requirement

·       Irrigation or couplant feed option

·       Wear-resistant contact surface option

·       Engraved part number or identification marking

·       Application-specific wedge design

·       OEM probe compatibility modification

Recommended Industries

·       Oil & Gas

·       Petrochemical Plants

·       Refineries

·       Power Plants

·       Pipeline and Process Piping Fabrication

·       Boiler and Pressure Vessel Fabrication

·       Heavy Engineering

·       Shipbuilding and Marine Fabrication

·       Plant Maintenance and Shutdown Inspection

·       NDT Service Companies

·       Inspection and Quality Control Laboratories

Why Choose TheSonic India PAUT A12 Series COD Wedges?

TheSonic India PAUT A12 Series COD Wedges are designed for dependable circumferential OD phased array weld inspection. The product combines Rexolite wedge material, COD curvature matching, stable outer-diameter contact, controlled beam positioning, and high-standard damping support for reliable inspection performance.

These wedges are suitable for customers requiring application-ready PAUT weld inspection accessories with A12 Probe Series compatibility, OEM probe adaptability, and customization support.

Contact Note

For technical details, probe compatibility confirmation, OD curvature selection, product customization, commercial quotation, or bulk supply requirements, please contact TheSonic India.

Email: i@thesonic.com
Brand: TheSonic India
