Weld Probe Wedges A3 Series

Part No: A310-1 - AOD angle Wedge 8.625" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 8.625" (Dual Scan Wedge set) pipe ranger coverable - 168.3mm(6.625") - 219.0mm(8.625")

Part No: A37 - AOD angle Wedge 4.5" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 4.5" (single side scan Wedge) pipe ranger coverable 101.6mm(4") - 114.3mm(4.5")

Part No: A311-1 - AOD angle Wedge 10.75" (Dual Scan Wedge set) for A3 phased Array probe

AOD angle Wedge 10.75" (Dual Scan Wedge set) pipe ranger coverable - 219.0mm(8.625") - 273.0mm(10.75")

Part No: A38 - AOD angle Wedge 5.563" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 5.563" (single side scan Wedge) pipe ranger coverable 114.3mm(4.5") - 141.3mm(5.563")

Part No: A312-1 - AOD angle Wedge 12.75" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 12.75" (Dual Scan Wedge set) pipe ranger coverable - 273.0mm(10.75") - 323.8mm(12.75")

Part No: A39 - AOD angle Wedge 6.625" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 6.625" (single side scan Wedge) pipe ranger coverable - 141.3mm(5.563") - 168.3mm(6.625")

Part No: A313-1 - AOD angle Wedge 16" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 16" (Dual Scan Wedge set) pipe ranger coverable - 323.8mm(12.75") - 406.4mm(16")

Part No: A310 - AOD angle Wedge 8.625" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 8.625" (single side scan Wedge) pipe ranger coverable - 168.3mm(6.625") - 219.0mm(8.625")

Part No: A314-1 - AOD angle Wedge 24" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 24" (Dual Scan Wedge set) pipe ranger coverable - 406.4mm(16") - 609.6mm(24")

Part No: A311 - AOD angle Wedge 10.75" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 10.75" (single side scan Wedge) pipe ranger coverable - 219.0mm(8.625") - 273.0mm(10.75")

Part No: A312 - AOD angle Wedge 12.75" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 12.75" (single side scan Wedge) pipe ranger coverable - 273.0mm(10.75") - 323.8mm(12.75")

Part No: A313 - AOD angle Wedge 16" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 16" (single side scan Wedge) pipe ranger coverable - 323.8mm(12.75") - 406.4mm(16")

Part no: A314 - AOD angle Wedge 24" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 24" (single side scan Wedge) pipe ranger coverable - 406.4mm(16") - 609.6mm(24")

Part No: A31-1 - Flat 0 degree Wedge (Dual Scan Wedge set) for A3 phased array probe

Flat 0 degree Wedge (Dual Scan Wedge set)

Part No: A32-1 - Flat angle Wedge (Dual Scan Wedge set) for A3 phased array probe

Flat angle Wedge (Dual Scan Wedge set)

Part no: A33-1 - AOD angle Wedge 2.375" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 2.375" (Dual Scan Wedge set) Tube ranger coverable 50.8mm(2") - 60.3mm(2.375")

Part No: A34-1 - AOD angle Wedge 2.875" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 2.875" (Dual Scan Wedge set) Tube ranger coverable 60.3mm(2.375") - 73.0mm(2.875")

Part No: A31 - Flat 0 degree Wedge (single side scan Wedge) for A3 phased array probe

Flat 0 degree Wedge (single side scan Wedge)

Part No: A35-1 - AOD angle Wedge 3.5" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 3.5" (Dual Scan Wedge set) pipe ranger coverable 73.0mm(2.875") - 88.9mm(3.5")

Part No: A32 - Flat angle Wedge (single side scan Wedge) for A3 phased array probe

Flat angle Wedge (single side scan Wedge)

Part No: A36-1 - AOD angle Wedge 4" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 4" (Dual Scan Wedge set) pipe ranger coverable 88.9mm(3.5") - 101.6mm(4")

Part No: A33 - AOD angle Wedge 2.375" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 2.375" (single side scan Wedge) Tube ranger coverable 50.8mm(2") - 60.3mm(2.375")

Part No: A37-1 - AOD angle Wedge 4.5" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 4.5" (Dual Scan Wedge set) pipe ranger coverable 101.6mm(4") - 114.3mm(4.5")

Part No: A34 - AOD angle Wedge 2.875" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 2.875" (single side scan Wedge) Tube ranger coverable 60.3mm(2.375") - 73.0mm(2.875")

Part No: A38-1 - AOD angle Wedge 5.563" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 5.563" (Dual Scan Wedge set) pipe ranger coverable 114.3mm(4.5") - 141.3mm(5.563")

Part No: A35 - AOD angle Wedge 3.5" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 3.5" (single side scan Wedge) pipe ranger coverable 73.0mm(2.875") - 88.9mm (3.5")

Part No: A36 - AOD angle Wedge 4" (single side scan Wedge) for A3 phased array probe

AOD angle Wedge 4" (single side scan Wedge) pipe ranger coverable 88.9mm(3.5") - 101.6mm(4")

Part No: A39-1 - AOD angle Wedge 6.625" (Dual Scan Wedge set) for A3 phased array probe

AOD angle Wedge 6.625" (Dual Scan Wedge set) pipe ranger coverable - 141.3mm(5.563") - 168.3mm(6.625")

Part No: A3-10 - Ten(10) set single side scan A3 Series Wedges

Ten(10) set single side scan A3 Series Wedges with AODs 4.5" to 24" & Flat angel, 0 degree Wedge. Set include Each 1 number from below specifications

Part No: A3-14 - Fourteen(14) set single side scan A3 Series Wedges

Fourteen(14) set single side scan A3 Series Wedges with AODs 2" to 24" & Flat angel, 0 degree Wedge. Set include Each 1 number from below specifications

Part No: A3-19 - Nineteen(19) set DUAL side scan A3 Series Wedges

Nineteen(19) set DUAL side scan A3 Series Wedges with AODs 4.5" to 24" & tow Flat angel, one 0 degree Wedge. Set include Each 2 number from below specifications

Part No: A3-27 - Twenty Seven (27) set dual side scan A3 Series Wedges

Twenty Seven (27) set dual side scan A3 Series Wedges with AODs 2" to 24" & Flat angel, one 0 degree Wedge. Set include Each 2 number from below specifications
